Industrial / Precision Die Casting
SFP Structural Part 11
Precision die-cast housing element for SFP transceiver modules, designed to deliver consistent mechanical performance across large production volumes. The component integrates into the module shell structure, supporting proper alignment of optical and electrical interfaces. Typical use cases include access layer networking equipment, fiber-to-the-premises systems, and industrial field devices.
Key Features
- Consistent mechanical performance across high-volume production batches
- Precision die-cast housing element designed for SFP transceiver module integration
- Tight wall thickness control minimizes signal interference within the enclosure
- Robust latch and retention geometry for secure cage engagement
- RoHS-compliant alloy composition suitable for global OEM supply chains
Key Specifications
- Product type: precision die-cast structural component
- Connector / hardware family: SFP
- Process: precision die casting with secondary machining or finishing as required by drawing
- Application focus: connector housing, cage, shell, heatsink carrier, or industrial structural part
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
SFP Structural Part 11 Specifications
Product typeprecision die-cast structural component
Connector / hardware familySFP
Processprecision die casting with secondary machining or finishing as required by drawing
Application focusconnector housing, cage, shell, heatsink carrier, or industrial structural part
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm alloy, dimensional tolerance, tooling status, surface finish, machining operations, inspection criteria, and drawing revision
Typical Applications
OEM SFP transceiver module enclosure manufacturing
Enterprise networking switch and router optical ports
Carrier-grade telecom equipment transceiver assemblies
Industrial automation optical communication modules
High-density data center interconnect hardware
Frequently Asked Questions
How does CZT ensure batch-to-batch consistency for this housing element?
CZT employs precision die casting tooling with controlled injection parameters and in-process dimensional inspection. Statistical process control (SPC) is applied to critical dimensions, ensuring each production lot meets the same mechanical specification as qualification samples.
Can this part be customized for proprietary SFP module designs?
Yes. CZT supports tooling modifications and custom die casting designs for OEMs requiring non-standard geometries, branding features, or additional mechanical interfaces, subject to minimum order quantities and tooling lead times.
What surface treatments are available for this housing element?
Available treatments include nickel plating, tin plating, and chromate conversion coating, each offering different levels of corrosion resistance and contact conductivity to suit specific environmental and EMI shielding requirements.
SFP Structural Part 11 Details
CategoryIndustrial
SubcategoryPrecision Die Casting
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
