SFP+Structural Part 12
Precision die-cast SFP+ structural part engineered to support the mechanical assembly of small form-factor pluggable modules in high-speed networking applications. Manufactured with tight tolerances to ensure reliable mating, secure latch function, and consistent thermal performance. Suited for deployment in 10G SFP+ transceivers used in telecommunications, cloud infrastructure, and industrial automation networks.
Key Features
- Supports mechanical assembly of SFP+ pluggable module sub-components
- Precision die casting maintains critical mating surface flatness and parallelism
- Designed for compatibility with standard SFP+ cage latch mechanisms
- High-strength alloy construction resists deformation under insertion forces
- Batch-to-batch dimensional repeatability validated through SPC monitoring
Key Specifications
- Product type: precision die-cast structural component
- Connector / hardware family: SFP
- Process: precision die casting with secondary machining or finishing as required by drawing
- Application focus: connector housing, cage, shell, heatsink carrier, or industrial structural part
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
SFP+Structural Part 12 Specifications
Product typeprecision die-cast structural component
Connector / hardware familySFP
Processprecision die casting with secondary machining or finishing as required by drawing
Application focusconnector housing, cage, shell, heatsink carrier, or industrial structural part
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm alloy, dimensional tolerance, tooling status, surface finish, machining operations, inspection criteria, and drawing revision
Typical Applications
SFP+ pluggable module mechanical sub-assembly production
Optical networking equipment transceiver frame components
High-speed backplane SFP+ interface module housings
Cloud data center 10G/25G transceiver structural parts
Broadcast and media infrastructure SFP+ module frames
