SFP Structural Part 12
SFP module structural part produced via precision die casting, offering tight dimensional tolerances that ensure compatibility with standard SFP cage and bail latch mechanisms. The component supports the structural integrity of the transceiver housing during installation and operation. Applied in Gigabit SFP modules for enterprise switches, optical transceivers, and WDM transmission systems.
Key Features
- Tight dimensional tolerances ensure plug compatibility across MSA-compliant SFP cages
- Precision die casting process delivers repeatable geometry for high-volume assembly
- Optimized draft angles and parting lines reduce post-cast finishing requirements
- Mechanical strength supports repeated insertion and extraction cycles reliably
- Alloy selection balances weight, conductivity, and structural rigidity
Key Specifications
- Product type: precision die-cast structural component
- Connector / hardware family: SFP
- Process: precision die casting with secondary machining or finishing as required by drawing
- Application focus: connector housing, cage, shell, heatsink carrier, or industrial structural part
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
SFP Structural Part 12 Specifications
Product typeprecision die-cast structural component
Connector / hardware familySFP
Processprecision die casting with secondary machining or finishing as required by drawing
Application focusconnector housing, cage, shell, heatsink carrier, or industrial structural part
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm alloy, dimensional tolerance, tooling status, surface finish, machining operations, inspection criteria, and drawing revision
Typical Applications
SFP module production for fiber optic networking equipment
Telecom base station optical transceiver assemblies
Industrial Ethernet switch SFP port hardware
Medical imaging and diagnostic optical communication modules
Broadcast and AV infrastructure SFP transceiver integration
Frequently Asked Questions
What is the typical dimensional tolerance range for this SFP structural part?
CZT's precision die casting process achieves tolerances within ±0.05 mm on critical mating dimensions, ensuring compatibility with standard SFP cage receptacles and host PCB layouts without requiring selective fitting or rework.
How many mating cycles is this structural part rated for?
The part is designed to support a minimum of 100 insertion/extraction cycles in line with SFP MSA mechanical durability guidelines, with actual service life dependent on mating force, environmental conditions, and surface finish specification.
Is this part suitable for use in industrial temperature environments?
Yes. The die-cast alloy and surface treatment options are selected to maintain dimensional stability and corrosion resistance across industrial operating temperature ranges, typically -40°C to +85°C, making it suitable for harsh deployment environments.
SFP Structural Part 12 Details
CategoryIndustrial
SubcategoryPrecision Die Casting
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
