Industrial / Precision Die Casting
SFP+Structural Part 13
SFP+ structural component produced through precision die casting, providing the mechanical framework necessary for reliable transceiver module performance. The casting delivers accurate dimensions and a quality surface finish that supports proper cage engagement and EMI shielding. Commonly integrated into 10G optical transceivers for data center, enterprise LAN, and metro network applications.
Key Features
- Provides mechanical framework for reliable SFP+ transceiver module operation
- Precision die casting ensures accurate alignment of optical and electrical interfaces
- Structural rigidity prevents housing deformation during repeated mating cycles
- Compatible with standard SFP+ bail latch and pull-tab retention systems
- Available with secondary machining for tight-tolerance critical features
Key Specifications
- Product type: precision die-cast structural component
- Connector / hardware family: SFP
- Process: precision die casting with secondary machining or finishing as required by drawing
- Application focus: connector housing, cage, shell, heatsink carrier, or industrial structural part
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
SFP+Structural Part 13 Specifications
Product typeprecision die-cast structural component
Connector / hardware familySFP
Processprecision die casting with secondary machining or finishing as required by drawing
Application focusconnector housing, cage, shell, heatsink carrier, or industrial structural part
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm alloy, dimensional tolerance, tooling status, surface finish, machining operations, inspection criteria, and drawing revision
Typical Applications
SFP+ transceiver mechanical framework for optical modules
Enterprise core switch 10G/25G port module assemblies
FTTH/FTTB optical network unit transceiver housings
Industrial Ethernet switch SFP+ module structural parts
Embedded computing SFP+ interface module frames
Frequently Asked Questions
What alignment features are incorporated into the SFP+ structural part design?
CZT's SFP+ structural parts include precision-cast guide rails, locating bosses, and datum surfaces that ensure accurate alignment of the optical sub-assembly and electrical connector within the housing. These features are dimensionally controlled to MSA specifications to guarantee proper cage engagement.
Can the structural part accommodate both LC duplex and MPO optical interface variants?
The base structural part geometry is designed around the standard SFP+ MSA envelope. Variants accommodating different optical interface configurations — including LC duplex and MPO — are available as separate part numbers with modified front-end geometry, produced from dedicated tooling.
What is the typical mating cycle durability of the die-cast housing?
CZT's die-cast SFP+ structural parts are designed to support a minimum of 100 mating cycles per SFP+ MSA requirements. The alloy selection and latch geometry are optimized to maintain dimensional integrity and retention force throughout the rated service life of the transceiver module.
SFP+Structural Part 13 Details
CategoryIndustrial
SubcategoryPrecision Die Casting
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
