SFP+Structural Part 14
Precision die-cast SFP+ structural part designed to deliver dimensional accuracy and mechanical durability in small form-factor transceiver assemblies. The component supports structural integrity and proper alignment within SFP+ module housings across high-cycle-count environments. Applicable in fiber-optic communication modules, network switches, and industrial connectivity equipment operating at 10G speeds.
Key Features
- Dimensional accuracy ensures drop-in compatibility with SFP+ MSA host cages
- Mechanical durability validated for extended service life in active transceivers
- Die-cast construction provides superior strength-to-weight ratio vs. stamped parts
- Tight tolerances on optical port and electrical connector mating surfaces
- Supports integration of EMI gaskets and thermal interface materials
Key Specifications
- Product type: precision die-cast structural component
- Connector / hardware family: SFP
- Process: precision die casting with secondary machining or finishing as required by drawing
- Application focus: connector housing, cage, shell, heatsink carrier, or industrial structural part
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
SFP+Structural Part 14 Specifications
Product typeprecision die-cast structural component
Connector / hardware familySFP
Processprecision die casting with secondary machining or finishing as required by drawing
Application focusconnector housing, cage, shell, heatsink carrier, or industrial structural part
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm alloy, dimensional tolerance, tooling status, surface finish, machining operations, inspection criteria, and drawing revision
Typical Applications
SFP+ module housing for carrier-grade telecom equipment
Data center top-of-rack switch transceiver assemblies
10G/25G CWDM optical transceiver structural components
High-reliability industrial SFP+ module enclosures
Avionics and defense SFP+ interface module frames
Frequently Asked Questions
How is dimensional accuracy verified before shipment of SFP+ structural parts?
CZT performs 100% visual inspection and sampling-based CMM dimensional inspection on all SFP+ structural part shipments. Critical dimensions — including cage mating surfaces, latch slot positions, and PCB standoff heights — are measured against approved drawings, with results documented in outgoing inspection records.
What is the hardness range of the die-cast alloy used in these parts?
Zinc alloy (Zamak 3/5) die-cast parts typically achieve a Brinell hardness of 82–91 HB, providing good wear resistance at latch and guide rail contact points. Aluminum alloy variants (e.g., ADC12) achieve 70–90 HB, offering a lighter alternative where weight is a design constraint.
Can CZT supply SFP+ structural parts with integrated EMI shielding features?
Yes. Die-cast metal housings inherently provide EMI shielding. CZT can incorporate design features such as spring finger slots, conductive gasket grooves, and shielding tabs into the casting to enhance EMI containment, meeting the shielding effectiveness requirements of the host system design.
SFP+Structural Part 14 Details
CategoryIndustrial
SubcategoryPrecision Die Casting
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
