Industrial / Precision Die Casting
SFP Structural Part 14
Die-cast SFP structural part designed to serve as a core mechanical element within the transceiver module enclosure, supporting both assembly integrity and end-user handling requirements. Its precision geometry facilitates consistent production yields and straightforward integration into module manufacturing lines. Applicable in fiber optic communication modules for data centers, ISP networks, and industrial control systems.
Key Features
- Core mechanical element providing structural integrity to SFP transceiver enclosures
- Die-cast construction withstands mechanical stress from repeated field mating
- Precision internal geometry supports accurate positioning of optical and electrical interfaces
- EMI shielding effectiveness enhanced by conductive alloy and surface plating options
- Designed to meet SFP MSA mechanical and dimensional compliance requirements
Key Specifications
- Product type: precision die-cast structural component
- Connector / hardware family: SFP
- Process: precision die casting with secondary machining or finishing as required by drawing
- Application focus: connector housing, cage, shell, heatsink carrier, or industrial structural part
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
SFP Structural Part 14 Specifications
Product typeprecision die-cast structural component
Connector / hardware familySFP
Processprecision die casting with secondary machining or finishing as required by drawing
Application focusconnector housing, cage, shell, heatsink carrier, or industrial structural part
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm alloy, dimensional tolerance, tooling status, surface finish, machining operations, inspection criteria, and drawing revision
Typical Applications
Core housing structure for SFP optical transceiver modules
High-reliability telecom and datacom transceiver enclosures
Defense and aerospace ruggedized SFP module assemblies
Industrial control system fiber optic communication hardware
Cloud infrastructure high-density optical interconnect modules
Frequently Asked Questions
What role does this part play as a core mechanical element in SFP modules?
This structural part forms the primary load-bearing enclosure of the SFP module, providing the mechanical reference for all internal subassemblies, protecting optical and electrical components from external mechanical stress, and ensuring dimensional compliance with host cage receptacles.
What EMI shielding performance can be expected from this die-cast part?
The conductive die-cast alloy, combined with optional nickel or tin plating, provides effective EMI shielding across the frequency ranges relevant to SFP data rates. Specific shielding effectiveness values depend on alloy selection, plating thickness, and seam design.
Is this part available with custom laser marking or branding?
Yes. CZT can apply laser marking, embossing, or pad printing to the exterior surfaces of this structural part for OEM branding, part number identification, or regulatory marking requirements, subject to surface area availability and order volume.
SFP Structural Part 14 Details
CategoryIndustrial
SubcategoryPrecision Die Casting
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
