Industrial / Precision Die Casting
SFP+Structural Part 16
Die-cast SFP+ structural component engineered for integration into 10G small form-factor transceiver housings requiring precise geometry and robust construction. The precision casting process ensures tight dimensional tolerances and a uniform surface finish critical for module performance and longevity. Typical applications include optical transceivers, fiber channel adapters, and high-density network switching equipment.
Key Features
- Precision die-cast construction ensures tight dimensional tolerances for SFP+ integration
- Engineered for 10G small form-factor transceiver housing assemblies
- High mechanical strength supports reliable module mating and retention
- Consistent batch-to-batch dimensional accuracy for automated assembly lines
- Surface finish optimized for EMI shielding and thermal dissipation
Key Specifications
- Product type: precision die-cast structural component
- Connector / hardware family: SFP
- Process: precision die casting with secondary machining or finishing as required by drawing
- Application focus: connector housing, cage, shell, heatsink carrier, or industrial structural part
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
SFP+Structural Part 16 Specifications
Product typeprecision die-cast structural component
Connector / hardware familySFP
Processprecision die casting with secondary machining or finishing as required by drawing
Application focusconnector housing, cage, shell, heatsink carrier, or industrial structural part
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm alloy, dimensional tolerance, tooling status, surface finish, machining operations, inspection criteria, and drawing revision
Typical Applications
10G SFP+ optical transceiver module housing assemblies
Data center switch and router line card transceivers
Industrial Ethernet switches requiring ruggedized SFP+ modules
Telecom OLT and ONU equipment SFP+ enclosures
High-density fiber channel storage networking transceivers
Frequently Asked Questions
What die casting alloy is used for this SFP+ structural part?
This component is typically produced using zinc or aluminum alloy die casting, selected for optimal balance of mechanical strength, dimensional stability, and EMI shielding performance required by SFP+ MSA specifications. Material confirmation is available upon request for specific procurement requirements.
Does this part comply with SFP+ MSA mechanical specifications?
Yes, the component is engineered to meet SFP+ Multi-Source Agreement (MSA) mechanical envelope requirements, ensuring compatibility with standard SFP+ cages and host board connectors across major switch and router platforms.
What dimensional tolerances are maintained during production?
Precision die casting processes maintain tolerances typically within ±0.05mm on critical mating surfaces, ensuring consistent fit and function across high-volume production runs suitable for automated transceiver assembly.
SFP+Structural Part 16 Details
CategoryIndustrial
SubcategoryPrecision Die Casting
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
