SFP+Structural Part 17
Precision die-cast SFP+ structural part designed to meet the mechanical requirements of small form-factor pluggable transceiver assemblies in high-speed networking. The component provides structural support, accurate module alignment, and effective electromagnetic shielding for reliable 10G data transmission. Widely used in enterprise switches, optical network units, and industrial communication platforms.
Key Features
- Meets SFP+ MSA mechanical envelope requirements for plug-in compatibility
- Precision die casting delivers repeatable geometry across high-volume production
- Robust wall thickness provides structural integrity under repeated insertion cycles
- Designed for seamless integration with standard SFP+ cage assemblies
- Compatible with both copper and optical SFP+ transceiver configurations
Key Specifications
- Product type: precision die-cast structural component
- Connector / hardware family: SFP
- Process: precision die casting with secondary machining or finishing as required by drawing
- Application focus: connector housing, cage, shell, heatsink carrier, or industrial structural part
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
SFP+Structural Part 17 Specifications
Product typeprecision die-cast structural component
Connector / hardware familySFP
Processprecision die casting with secondary machining or finishing as required by drawing
Application focusconnector housing, cage, shell, heatsink carrier, or industrial structural part
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm alloy, dimensional tolerance, tooling status, surface finish, machining operations, inspection criteria, and drawing revision
Typical Applications
Small form-factor pluggable transceiver module enclosures
Enterprise LAN and WAN switching infrastructure transceivers
Wireless backhaul equipment SFP+ module housings
Industrial automation network SFP+ transceiver assemblies
Broadcasting and media networking SFP+ equipment
Frequently Asked Questions
How does precision die casting benefit SFP+ structural part performance?
Precision die casting produces near-net-shape components with tight tolerances, eliminating secondary machining on most surfaces. This ensures consistent mating dimensions critical for SFP+ hot-plug reliability, reduces assembly rejection rates, and supports high-volume manufacturing economics.
Can this structural part be customized for proprietary transceiver designs?
Yes, CZT supports tooling modifications and custom die casting designs for OEM transceiver manufacturers requiring non-standard form factors or additional mechanical features, with engineering support available for DFM review.
What surface treatments are available for this component?
Standard options include nickel plating, tin plating, and chromate conversion coating to enhance corrosion resistance and contact conductivity. Custom surface treatments can be specified based on end-use environment and compliance requirements.
SFP+Structural Part 17 Details
CategoryIndustrial
SubcategoryPrecision Die Casting
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
