SFP+Structural Part 18
SFP+ structural component produced through precision die casting, offering consistent dimensional accuracy and mechanical strength for transceiver module applications. Designed to ensure secure module retention, proper cage mating, and effective EMI containment throughout the product lifecycle. Suitable for use in 10G SFP+ transceivers deployed in data centers, carrier networks, and industrial automation systems.
Key Features
- Consistent dimensional accuracy across production batches minimizes assembly variation
- Die-cast construction provides superior mechanical rigidity versus stamped alternatives
- Optimized parting line placement preserves critical mating surface integrity
- Suitable for high-volume automated transceiver assembly processes
- Mechanical performance validated for SFP+ hot-plug insertion cycle requirements
Key Specifications
- Product type: precision die-cast structural component
- Connector / hardware family: SFP
- Process: precision die casting with secondary machining or finishing as required by drawing
- Application focus: connector housing, cage, shell, heatsink carrier, or industrial structural part
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
SFP+Structural Part 18 Specifications
Product typeprecision die-cast structural component
Connector / hardware familySFP
Processprecision die casting with secondary machining or finishing as required by drawing
Application focusconnector housing, cage, shell, heatsink carrier, or industrial structural part
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm alloy, dimensional tolerance, tooling status, surface finish, machining operations, inspection criteria, and drawing revision
Typical Applications
High-volume SFP+ transceiver OEM manufacturing lines
Cloud data center 10G optical interconnect modules
Metro Ethernet and SONET/SDH network transceivers
Military and industrial ruggedized SFP+ module housings
Test and measurement equipment SFP+ interface modules
Frequently Asked Questions
What is the typical production lead time for this SFP+ structural part?
Standard production lead time is 4–6 weeks for repeat orders with established tooling. New tooling development typically requires 6–8 weeks including first article inspection. CZT maintains buffer stock programs for qualified high-volume customers to support just-in-time delivery.
How is dimensional accuracy verified during production?
CZT employs CMM (Coordinate Measuring Machine) inspection and go/no-go gauge verification on critical dimensions. First article inspection reports (FAIR) are available, and statistical process control is applied to monitor key characteristics throughout production runs.
Is this component RoHS compliant?
Yes, this die-cast SFP+ structural part is manufactured in compliance with RoHS 2 (EU Directive 2011/65/EU) and REACH regulations, using compliant alloys and surface treatment chemistries. Compliance documentation is available upon request.
SFP+Structural Part 18 Details
CategoryIndustrial
SubcategoryPrecision Die Casting
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
