Industrial / Precision Die Casting
SFP+Structural Part 19
Precision die-cast structural component designed for SFP+ transceiver modules, manufactured to tight dimensional tolerances for reliable module assembly. This housing part provides the mechanical framework that ensures proper alignment and secure mating of SFP+ connectors. Commonly used in high-speed networking equipment, data center switches, and fiber optic communication systems operating at 10Gbps and above.
Key Features
- Tight dimensional tolerances ensure reliable SFP+ module-to-cage mating
- Precision die casting supports complex internal geometry without secondary machining
- Mechanical design accommodates standard SFP+ bail latch and retention mechanisms
- High-strength alloy construction withstands repeated hot-plug insertion forces
- Batch consistency supports zero-defect quality targets in transceiver assembly
Key Specifications
- Product type: precision die-cast structural component
- Connector / hardware family: SFP
- Process: precision die casting with secondary machining or finishing as required by drawing
- Application focus: connector housing, cage, shell, heatsink carrier, or industrial structural part
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
SFP+Structural Part 19 Specifications
Product typeprecision die-cast structural component
Connector / hardware familySFP
Processprecision die casting with secondary machining or finishing as required by drawing
Application focusconnector housing, cage, shell, heatsink carrier, or industrial structural part
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm alloy, dimensional tolerance, tooling status, surface finish, machining operations, inspection criteria, and drawing revision
Typical Applications
SFP+ transceiver modules for 10GbE data networking
CWDM and DWDM optical transceiver housing components
Carrier-grade telecom equipment SFP+ module enclosures
Industrial IoT gateway SFP+ network interface modules
Passive optical network (PON) OLT transceiver assemblies
Frequently Asked Questions
What mechanical tests are performed on these SFP+ structural parts?
Components undergo dimensional inspection, insertion/extraction force testing, and structural integrity checks per SFP+ MSA mechanical requirements. Salt spray and thermal cycling tests are available for customers requiring environmental qualification data for harsh deployment environments.
Can CZT provide first article inspection reports for this part?
Yes, CZT provides full FAIR documentation including dimensional reports, material certifications, and surface treatment verification. Reports are generated per customer-specified formats or to AS9102 standards upon request.
What minimum order quantities apply to this component?
MOQ varies by configuration and surface treatment specification, typically starting at 5,000 pieces for standard variants. CZT offers flexible MOQ arrangements for qualified OEM customers during product development and ramp phases.
SFP+Structural Part 19 Details
CategoryIndustrial
SubcategoryPrecision Die Casting
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
