Industrial / Precision Die Casting
SFP+Structural Part 2
Die-cast SFP+ structural part offering robust mechanical support for transceiver module construction, engineered for consistent fit and finish across high-volume production runs. Its precision-formed geometry ensures compatibility with standard SFP+ cage assemblies and PCB mounting configurations. Suitable for use in enterprise networking hardware, telecom infrastructure, and industrial Ethernet applications.
Key Features
- Robust mechanical support structure for SFP+ transceiver module construction
- Engineered for consistent performance across extended operating temperature ranges
- Die-cast precision geometry ensures accurate PCB and optical subassembly alignment
- High-cycle durability supports SFP+ hot-plug reliability requirements
- Designed for compatibility with industry-standard SFP+ cage connector systems
Key Specifications
- Product type: precision die-cast structural component
- Connector / hardware family: SFP
- Process: precision die casting with secondary machining or finishing as required by drawing
- Application focus: connector housing, cage, shell, heatsink carrier, or industrial structural part
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
SFP+Structural Part 2 Specifications
Product typeprecision die-cast structural component
Connector / hardware familySFP
Processprecision die casting with secondary machining or finishing as required by drawing
Application focusconnector housing, cage, shell, heatsink carrier, or industrial structural part
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm alloy, dimensional tolerance, tooling status, surface finish, machining operations, inspection criteria, and drawing revision
Typical Applications
10G SFP+ transceiver module mechanical housing assemblies
Enterprise core and aggregation switch transceiver modules
Optical transport network (OTN) SFP+ interface components
Data center top-of-rack switch SFP+ transceivers
5G fronthaul and midhaul optical transceiver modules
Frequently Asked Questions
How does this SFP+ structural part contribute to transceiver thermal management?
The die-cast metal housing acts as a heat spreader, conducting heat away from internal optical and electronic components to the host cage. Alloy selection and surface finish can be optimized to improve thermal conductivity for high-power SFP+ variants operating at elevated ambient temperatures.
Is this part suitable for use in extended temperature range SFP+ modules?
Yes, the die-cast construction maintains dimensional stability across the industrial temperature range (-40°C to +85°C), making it suitable for extended temperature SFP+ modules deployed in outdoor, industrial, and telecom central office environments.
What alloy options are available for this structural component?
Zinc alloy (Zamak series) and aluminum alloy (ADC12) are standard options. Zinc offers superior dimensional precision and surface finish for complex geometries, while aluminum provides a lower weight-to-strength ratio for weight-sensitive applications.
SFP+Structural Part 2 Details
CategoryIndustrial
SubcategoryPrecision Die Casting
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
