Industrial / Precision Die Casting
SFP Structural Part 2
Precision die-cast structural component for SFP modules, engineered to provide dimensional accuracy and mechanical robustness throughout the transceiver lifecycle. The part supports proper housing closure and alignment of internal optical subassemblies within the SFP form factor. Widely used in Gigabit Ethernet transceivers, CWDM/DWDM modules, and industrial fiber optic communication equipment.
Key Features
- Dimensional accuracy and mechanical robustness engineered for SFP module integration
- Precision die casting ensures repeatable geometry across large production volumes
- Alloy composition selected for optimal strength, weight, and corrosion resistance
- Compatible with standard SFP MSA mechanical envelope and cage receptacles
- Supports both single-mode and multimode optical SFP module configurations
Key Specifications
- Product type: precision die-cast structural component
- Connector / hardware family: SFP
- Process: precision die casting with secondary machining or finishing as required by drawing
- Application focus: connector housing, cage, shell, heatsink carrier, or industrial structural part
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
SFP Structural Part 2 Specifications
Product typeprecision die-cast structural component
Connector / hardware familySFP
Processprecision die casting with secondary machining or finishing as required by drawing
Application focusconnector housing, cage, shell, heatsink carrier, or industrial structural part
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm alloy, dimensional tolerance, tooling status, surface finish, machining operations, inspection criteria, and drawing revision
Typical Applications
SFP module structural housing for enterprise networking equipment
Optical transceiver production for ISP and carrier networks
Industrial Ethernet and PROFINET optical communication modules
Storage area network (SAN) fiber channel transceiver assemblies
Smart grid and utility automation optical communication hardware
Frequently Asked Questions
How does SFP Structural Part 2 differ from standard off-the-shelf SFP housings?
CZT's precision die casting process delivers tighter dimensional control and more consistent mechanical properties than many commodity housings, making this part suitable for OEMs requiring reliable performance across high-volume production runs and demanding deployment environments.
What alloy options are available for this structural component?
CZT offers zinc alloy (Zamak series) and aluminum alloy options. Zinc alloys provide superior casting detail and plating adhesion, while aluminum alloys offer a better strength-to-weight ratio for applications where module weight is a consideration.
What is the minimum order quantity for this part?
Minimum order quantities vary by configuration and surface finish. Contact CZT's sales team for current MOQ, lead time, and pricing information based on your specific volume and delivery requirements.
SFP Structural Part 2 Details
CategoryIndustrial
SubcategoryPrecision Die Casting
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
