Industrial / Precision Die Casting
SFP Structural Part
Precision die-cast structural component for standard SFP transceiver modules, manufactured to meet the dimensional requirements of the SFP MSA specification. The part provides essential mechanical support for the module housing, ensuring consistent fit within SFP cage connectors. Suitable for Gigabit Ethernet, Fibre Channel, and SONET/SDH optical networking applications.
Key Features
- Precision die-cast structural housing for standard SFP transceiver module assemblies
- Manufactured to SFP MSA mechanical envelope and dimensional tolerances
- Integrated latch and bail mechanism mounting features for standard SFP form factor
- Surface finish provides EMI shielding continuity with host cage assembly
- High-volume die casting process ensures consistent part-to-part dimensional repeatability
Key Specifications
- Product type: precision die-cast structural component
- Connector / hardware family: SFP
- Process: precision die casting with secondary machining or finishing as required by drawing
- Application focus: connector housing, cage, shell, heatsink carrier, or industrial structural part
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
SFP Structural Part Specifications
Product typeprecision die-cast structural component
Connector / hardware familySFP
Processprecision die casting with secondary machining or finishing as required by drawing
Application focusconnector housing, cage, shell, heatsink carrier, or industrial structural part
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm alloy, dimensional tolerance, tooling status, surface finish, machining operations, inspection criteria, and drawing revision
Typical Applications
Standard 1G SFP optical and copper transceiver module housings
SFP module structural frames for telecom and datacom equipment
Fiber channel and Gigabit Ethernet SFP transceiver assemblies
Industrial SFP modules requiring robust mechanical enclosure
OEM SFP module manufacturers requiring MSA-compliant structural parts
Frequently Asked Questions
What dimensional standards does the SFP structural part conform to?
The structural part is manufactured to conform to the SFP Multi-Source Agreement (MSA) mechanical specification, which defines the outer envelope, PCB edge connector interface, and bail latch geometry. This ensures compatibility with standard SFP host cages from all major connector manufacturers.
What die casting alloy is used and how does it affect EMI performance?
The part is cast from zinc or aluminum alloy, both of which provide good electrical conductivity for EMI shielding continuity when the module is seated in the host cage. The alloy selection and surface finish are optimized to maintain low-impedance contact with the cage ground path.
Can the SFP structural part be customized for proprietary module designs?
Yes, CZT supports custom die casting tooling for SFP structural parts with modified dimensions, additional mounting features, or proprietary form factors. NRE tooling costs and lead times apply. CZT provides DFM review, prototype samples, and first-article inspection before volume production release.
SFP Structural Part Details
CategoryIndustrial
SubcategoryPrecision Die Casting
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
