Industrial / Precision Die Casting
SFP Structural Part 3
Precision die-cast structural component designed for SFP (Small Form-factor Pluggable) transceiver assemblies, offering tight dimensional tolerances and reliable mechanical support. Manufactured using high-pressure die casting for consistent part geometry and surface finish. Commonly used in fiber optic and copper SFP modules for networking switches, routers, and telecommunications equipment.
Key Features
- Engineered for SFP (Small Form-factor Pluggable) transceiver assembly structural requirements
- Precision die casting delivers consistent wall thickness and internal cavity geometry
- Mechanical compliance with SFP MSA specification for universal cage compatibility
- Surface finish options support EMI containment and environmental protection
- High-volume production capability with stable tooling and process control
Key Specifications
- Product type: precision die-cast structural component
- Connector / hardware family: SFP
- Process: precision die casting with secondary machining or finishing as required by drawing
- Application focus: connector housing, cage, shell, heatsink carrier, or industrial structural part
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
SFP Structural Part 3 Specifications
Product typeprecision die-cast structural component
Connector / hardware familySFP
Processprecision die casting with secondary machining or finishing as required by drawing
Application focusconnector housing, cage, shell, heatsink carrier, or industrial structural part
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm alloy, dimensional tolerance, tooling status, surface finish, machining operations, inspection criteria, and drawing revision
Typical Applications
SFP transceiver module production for networking OEMs
Fiber optic communication hardware for data center deployments
Telecom access network optical transceiver assemblies
Industrial machine vision and sensor optical interfaces
Military and ruggedized communication system SFP modules
Frequently Asked Questions
What makes precision die casting the preferred process for SFP structural parts?
Precision die casting enables complex geometries, tight tolerances, and high surface quality in a single operation, making it cost-effective for high-volume SFP module production. It also provides the mechanical density and EMI shielding properties that machined or injection-molded alternatives cannot match.
How does CZT validate dimensional compliance for this SFP structural part?
CZT uses coordinate measuring machines (CMM) and optical measurement systems to verify critical dimensions against MSA SFP mechanical drawings. First article inspection reports and ongoing SPC data are available to OEM customers upon request.
Can this part be supplied with pre-applied thermal interface material?
Yes, CZT can coordinate value-added assembly services including application of thermal interface pads or compounds to designated surfaces, reducing assembly steps for customers integrating this part into thermally managed SFP module designs.
SFP Structural Part 3 Details
CategoryIndustrial
SubcategoryPrecision Die Casting
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
