SFP+Structural Part 4
Precision die-cast housing component for SFP+ transceiver assemblies, produced with close tolerances to meet the mechanical requirements of the SFP+ MSA standard. The part contributes to the structural integrity of the module, protecting internal optical and electrical elements. Widely applied in switches, routers, and optical transport equipment requiring 10G connectivity.
Key Features
- Close-tolerance die casting meets SFP+ MSA housing dimensional requirements
- Precision internal cavity geometry ensures accurate optical subassembly positioning
- Mechanical design supports standard SFP+ latch and de-latch mechanisms
- Alloy construction provides effective EMI containment for 10G signal integrity
- Production-validated for high-volume automated transceiver assembly compatibility
Key Specifications
- Product type: precision die-cast structural component
- Connector / hardware family: SFP
- Process: precision die casting with secondary machining or finishing as required by drawing
- Application focus: connector housing, cage, shell, heatsink carrier, or industrial structural part
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
SFP+Structural Part 4 Specifications
Product typeprecision die-cast structural component
Connector / hardware familySFP
Processprecision die casting with secondary machining or finishing as required by drawing
Application focusconnector housing, cage, shell, heatsink carrier, or industrial structural part
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm alloy, dimensional tolerance, tooling status, surface finish, machining operations, inspection criteria, and drawing revision
Typical Applications
SFP+ transceiver housing for 10G LR and SR optical modules
High-density line card SFP+ transceiver assemblies
Ruggedized SFP+ modules for transportation and energy sectors
Campus and metro network SFP+ optical interface modules
OEM white-box switch SFP+ transceiver components
Frequently Asked Questions
What tolerances are held on the SFP+ plug interface dimensions?
Critical plug interface dimensions conform to SFP+ MSA mechanical specifications, with key mating features held to ±0.05mm or better. This ensures reliable engagement with standard SFP+ cage connectors from major suppliers including Molex, TE Connectivity, and Amphenol.
Does CZT offer design support for custom SFP+ housing variants?
CZT's engineering team provides DFM (Design for Manufacturability) consultation, tooling design, and prototype development services for custom SFP+ housing configurations. This includes support for modified form factors, additional mounting features, and application-specific mechanical requirements.
How are tooling and production quality maintained over long production runs?
CZT implements scheduled die maintenance programs and periodic dimensional audits to ensure tooling remains within specification throughout its service life. Statistical process control data is maintained and available for customer quality system audits.
SFP+Structural Part 4 Details
CategoryIndustrial
SubcategoryPrecision Die Casting
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
