Industrial / Precision Die Casting
SFP Structural Part 4
Die-cast SFP structural part engineered to provide stable housing and alignment for small form-factor pluggable transceiver modules. Its precision casting construction ensures repeatable fitment and structural integrity across high-volume production runs. Suitable for use in data center networking hardware, industrial Ethernet switches, and optical communication devices.
Key Features
- Stable housing and alignment geometry for small form-factor pluggable transceivers
- Die-cast construction provides rigid support for optical subassembly positioning
- Precision mating surfaces ensure reliable engagement with SFP cage receptacles
- Latch mechanism geometry engineered for smooth insertion and positive retention
- Alloy and plating options available for varied environmental protection requirements
Key Specifications
- Product type: precision die-cast structural component
- Connector / hardware family: SFP
- Process: precision die casting with secondary machining or finishing as required by drawing
- Application focus: connector housing, cage, shell, heatsink carrier, or industrial structural part
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
SFP Structural Part 4 Specifications
Product typeprecision die-cast structural component
Connector / hardware familySFP
Processprecision die casting with secondary machining or finishing as required by drawing
Application focusconnector housing, cage, shell, heatsink carrier, or industrial structural part
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm alloy, dimensional tolerance, tooling status, surface finish, machining operations, inspection criteria, and drawing revision
Typical Applications
SFP transceiver alignment housing for optical networking modules
High-cycle-life SFP modules for field-replaceable network equipment
Telecom central office and remote terminal optical transceivers
Industrial automation fiber optic communication module assemblies
Video surveillance and security system optical SFP hardware
Frequently Asked Questions
How does this part ensure accurate alignment of SFP optical subassemblies?
The precision die-cast internal geometry incorporates locating features and datum surfaces that constrain optical subassembly position within the module envelope, maintaining the fiber alignment tolerances required for low insertion loss and consistent optical performance.
What latch retention force does the housing geometry support?
The latch geometry is designed to meet SFP MSA retention force requirements, providing positive module retention in the host cage while allowing tool-free extraction. Specific retention force values are validated during first article testing against MSA mechanical test procedures.
Is this structural part compatible with SFP+ (enhanced SFP) module designs?
The base mechanical envelope is compatible with SFP+ form factor requirements. However, customers should confirm specific dimensional requirements with CZT's engineering team, as SFP+ modules may have additional thermal or electrical interface considerations.
SFP Structural Part 4 Details
CategoryIndustrial
SubcategoryPrecision Die Casting
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
