Industrial / Precision Die Casting
SFP+Structural Part 5
SFP+ transceiver structural part manufactured via precision die casting, delivering consistent dimensional accuracy essential for reliable plug-and-play module performance. Designed to integrate seamlessly into standard SFP+ module housings, it supports proper latching and extraction mechanisms. Typical applications include data center interconnects, storage area networks, and high-density line cards.
Key Features
- Precision die casting delivers dimensional accuracy essential for SFP+ module assembly
- Consistent part geometry reduces rejection rates in automated assembly processes
- Mechanical structure supports reliable optical fiber alignment within transceiver
- Surface finish options available for enhanced corrosion resistance and conductivity
- Designed to withstand SFP+ MSA-specified insertion and extraction cycle counts
Key Specifications
- Product type: precision die-cast structural component
- Connector / hardware family: SFP
- Process: precision die casting with secondary machining or finishing as required by drawing
- Application focus: connector housing, cage, shell, heatsink carrier, or industrial structural part
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
SFP+Structural Part 5 Specifications
Product typeprecision die-cast structural component
Connector / hardware familySFP
Processprecision die casting with secondary machining or finishing as required by drawing
Application focusconnector housing, cage, shell, heatsink carrier, or industrial structural part
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm alloy, dimensional tolerance, tooling status, surface finish, machining operations, inspection criteria, and drawing revision
Typical Applications
SFP+ transceiver structural enclosures for fiber optic networking
Hyperscale data center 10G optical interconnect modules
Industrial Ethernet SFP+ modules for factory automation
Submarine and long-haul optical network SFP+ transceivers
Medical imaging and diagnostics network SFP+ interface modules
Frequently Asked Questions
What is the dimensional repeatability of this die-cast SFP+ structural part?
CZT's precision die casting process achieves Cpk ≥1.33 on critical dimensions under normal production conditions, ensuring consistent part quality suitable for automated assembly with minimal manual sorting or rework.
Can this component be supplied with pre-applied EMI gasket features?
Yes, CZT can supply components with integrated EMI gasket grooves or pre-applied conductive elastomer gaskets as part of the finished component, reducing assembly steps and ensuring consistent EMI shielding performance in the final transceiver module.
What packaging options are available to protect parts during shipping?
Components are available in anti-static tray, tape-and-reel, or bulk packaging configurations. Custom packaging to customer-specified formats is available for direct line-feed delivery to automated assembly equipment.
SFP+Structural Part 5 Details
CategoryIndustrial
SubcategoryPrecision Die Casting
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
