Industrial / Precision Die Casting
SFP+Structural Part 6
Die-cast precision structural component for SFP+ modules, engineered to provide mechanical stability and accurate form factor compliance within the transceiver assembly. Its construction supports thermal management and EMI shielding requirements common in high-speed optical modules. Used across telecommunications, enterprise networking, and industrial automation platforms.
Key Features
- Engineered die-cast geometry provides mechanical stability for SFP+ module enclosures
- Accurate form factor ensures correct fit within standard SFP+ host cage systems
- High-pressure die casting produces dense, low-porosity structure for structural integrity
- Designed for compatibility with SFP+ MSA-compliant optical and copper transceivers
- Supports integration of standard SFP+ locking and release latch mechanisms
Key Specifications
- Product type: precision die-cast structural component
- Connector / hardware family: SFP
- Process: precision die casting with secondary machining or finishing as required by drawing
- Application focus: connector housing, cage, shell, heatsink carrier, or industrial structural part
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
SFP+Structural Part 6 Specifications
Product typeprecision die-cast structural component
Connector / hardware familySFP
Processprecision die casting with secondary machining or finishing as required by drawing
Application focusconnector housing, cage, shell, heatsink carrier, or industrial structural part
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm alloy, dimensional tolerance, tooling status, surface finish, machining operations, inspection criteria, and drawing revision
Typical Applications
SFP+ module enclosures for enterprise and carrier networking
10G BiDi and WDM transceiver housing components
Railway and transportation SFP+ ruggedized module housings
Power utility substation SFP+ communication module enclosures
Broadcast video over IP SFP+ interface module assemblies
Frequently Asked Questions
How does high-pressure die casting improve the mechanical properties of this part?
High-pressure die casting forces molten alloy into the die at high velocity, producing a dense, fine-grained microstructure with minimal porosity. This results in superior tensile strength, hardness, and dimensional stability compared to gravity casting or machined alternatives.
What are the standard plating options for this SFP+ structural component?
Standard plating options include bright nickel, matte nickel, tin-lead-free, and gold flash over nickel. Selection depends on contact conductivity requirements, corrosion resistance specifications, and RoHS compliance needs of the end application.
Is this part compatible with active optical cable (AOC) SFP+ assemblies?
Yes, the mechanical envelope and internal geometry are compatible with both standard pluggable transceiver and active optical cable SFP+ assembly configurations, provided the AOC design conforms to SFP+ MSA mechanical specifications.
SFP+Structural Part 6 Details
CategoryIndustrial
SubcategoryPrecision Die Casting
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
