Industrial / Precision Die Casting
SFP Structural Part 6
SFP module structural part produced via precision die casting, providing the mechanical framework necessary for secure transceiver installation and EMI shielding. The component's tight tolerances support reliable signal integrity in high-speed data transmission applications. Typical end uses include managed switches, media converters, and fiber channel storage networking equipment.
Key Features
- Mechanical framework enabling secure transceiver subassembly integration within SFP modules
- Precision die casting provides consistent structural geometry across production volumes
- Robust enclosure design protects internal optical and electrical components from damage
- MSA-compliant external dimensions ensure compatibility with standard SFP host cages
- Available with multiple surface finish options for corrosion and EMI protection
Key Specifications
- Product type: precision die-cast structural component
- Connector / hardware family: SFP
- Process: precision die casting with secondary machining or finishing as required by drawing
- Application focus: connector housing, cage, shell, heatsink carrier, or industrial structural part
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
SFP Structural Part 6 Specifications
Product typeprecision die-cast structural component
Connector / hardware familySFP
Processprecision die casting with secondary machining or finishing as required by drawing
Application focusconnector housing, cage, shell, heatsink carrier, or industrial structural part
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm alloy, dimensional tolerance, tooling status, surface finish, machining operations, inspection criteria, and drawing revision
Typical Applications
SFP module mechanical framework for optical networking OEMs
Secure transceiver enclosure for harsh industrial environments
Telecom and datacom SFP module high-volume production
Fiber channel and InfiniBand SFP transceiver assemblies
Smart manufacturing and Industry 4.0 optical communication modules
Frequently Asked Questions
What structural protection does this die-cast part provide for SFP module internals?
The die-cast enclosure provides mechanical protection against impact, vibration, and handling stress during module installation and field operation. The dense alloy structure also acts as an EMI shield, protecting sensitive optical and electrical subassemblies from external interference.
How does CZT manage tooling maintenance to ensure long-term dimensional consistency?
CZT implements scheduled die casting tooling inspection and maintenance programs, including cavity measurement, surface reconditioning, and wear monitoring. Tooling life data is tracked to trigger proactive refurbishment before dimensional drift affects part quality.
What certifications or quality standards apply to this SFP structural part?
CZT operates under ISO 9001 quality management systems. Parts can be supplied with RoHS compliance documentation and material certifications. Customers requiring additional certifications such as IATF 16949 or specific industry standards should discuss requirements with CZT's quality team.
SFP Structural Part 6 Details
CategoryIndustrial
SubcategoryPrecision Die Casting
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
