Industrial / Precision Die Casting
SFP+Structural Part 7
Precision die-cast SFP+ structural part that forms a key mechanical element of the transceiver module enclosure, ensuring dimensional consistency and assembly repeatability. The component is suited for integration into both single-mode and multimode SFP+ module designs. Applicable in fiber channel systems, metro Ethernet equipment, and high-performance computing interconnects.
Key Features
- Key mechanical element of SFP+ transceiver module enclosure structure
- Precision die casting ensures accurate enclosure geometry for optical alignment
- Robust construction supports reliable performance over thousands of mating cycles
- Dimensional control maintains SFP+ MSA plug interface compliance
- Compatible with standard SFP+ cage systems from major connector manufacturers
Key Specifications
- Product type: precision die-cast structural component
- Connector / hardware family: SFP
- Process: precision die casting with secondary machining or finishing as required by drawing
- Application focus: connector housing, cage, shell, heatsink carrier, or industrial structural part
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
SFP+Structural Part 7 Specifications
Product typeprecision die-cast structural component
Connector / hardware familySFP
Processprecision die casting with secondary machining or finishing as required by drawing
Application focusconnector housing, cage, shell, heatsink carrier, or industrial structural part
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm alloy, dimensional tolerance, tooling status, surface finish, machining operations, inspection criteria, and drawing revision
Typical Applications
Core structural element of 10G SFP+ transceiver module enclosures
High-reliability SFP+ modules for defense and aerospace networking
Smart grid and energy automation SFP+ communication modules
Campus fiber backbone SFP+ transceiver assemblies
Video surveillance and security network SFP+ interface modules
Frequently Asked Questions
What role does this structural part play in the SFP+ transceiver assembly?
This component forms a primary structural element of the SFP+ module enclosure, providing the mechanical framework that houses the optical subassembly, PCB, and connector interface. It maintains critical alignment tolerances and provides the plug geometry required for cage engagement.
How does CZT ensure mating cycle durability for this component?
Material selection, surface hardness, and plating thickness are optimized to meet SFP+ MSA requirements for a minimum of 200 mating cycles. Accelerated wear testing is available for customers requiring validation data for extended-cycle applications.
Can CZT supply this part with secondary machining operations included?
Yes, CZT offers value-added services including CNC machining of critical surfaces, tapping, reaming, and deburring as part of a complete supply solution, reducing the number of suppliers in the customer's manufacturing chain.
SFP+Structural Part 7 Details
CategoryIndustrial
SubcategoryPrecision Die Casting
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
