Industrial / Precision Die Casting
SFP Structural Part 7
Precision die-cast structural element for SFP transceiver assemblies, offering robust mechanical support and accurate interface alignment in compact form-factor designs. High-pressure casting ensures consistent material density and surface quality across production batches. Used in optical networking modules, industrial field switches, and broadband access equipment.
Key Features
- Precision die-cast zinc or aluminum alloy construction for dimensional consistency
- Tight dimensional tolerances ensure accurate SFP transceiver module alignment
- Robust mechanical structure withstands repeated mating and unmating cycles
- Surface finish compatible with EMI shielding and grounding requirements
- Designed to meet SFP MSA mechanical envelope specifications
Key Specifications
- Product type: precision die-cast structural component
- Connector / hardware family: SFP
- Process: precision die casting with secondary machining or finishing as required by drawing
- Application focus: connector housing, cage, shell, heatsink carrier, or industrial structural part
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
SFP Structural Part 7 Specifications
Product typeprecision die-cast structural component
Connector / hardware familySFP
Processprecision die casting with secondary machining or finishing as required by drawing
Application focusconnector housing, cage, shell, heatsink carrier, or industrial structural part
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm alloy, dimensional tolerance, tooling status, surface finish, machining operations, inspection criteria, and drawing revision
Typical Applications
SFP transceiver module housing in enterprise switching equipment
Fiber channel storage area network interface assemblies
Industrial Ethernet SFP cage structural reinforcement
Telecom line card SFP port mechanical support
Data center top-of-rack switch transceiver assemblies
Frequently Asked Questions
What alloy is used in the die-casting of SFP Structural Part 7?
The part is typically produced from zinc or aluminum die-cast alloy selected for its combination of mechanical strength, dimensional stability, and surface finish quality. Specific alloy grade can be confirmed with CZT engineering upon request for your application requirements.
Does this structural part comply with SFP MSA mechanical specifications?
Yes, the part is engineered to conform to SFP Multi-Source Agreement (MSA) mechanical envelope requirements, ensuring compatibility with standard SFP cages and host board layouts from major switch and router OEMs.
What surface treatments are available for EMI shielding performance?
Available surface treatments include nickel plating, tin plating, and selective conductive coatings to meet EMI shielding and grounding continuity requirements. CZT can accommodate custom surface finish specifications based on system-level EMI compliance needs.
SFP Structural Part 7 Details
CategoryIndustrial
SubcategoryPrecision Die Casting
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
