Industrial / Precision Die Casting
SFP+Structural Part 8
SFP+ module structural component produced through precision die casting, offering reliable mechanical performance and dimensional stability under repeated insertion and extraction cycles. Designed to conform to SFP+ MSA housing specifications, it supports secure module retention within host cages. Common applications include network switches, optical line terminals, and industrial communication gateways.
Key Features
- Reliable mechanical performance across SFP+ module operating life requirements
- Precision die casting maintains dimensional integrity under thermal cycling conditions
- Structural design accommodates standard SFP+ PCB and optical engine subassemblies
- High-volume production capability supports large-scale transceiver manufacturing programs
- Quality management system certified to ISO 9001 for consistent production output
Key Specifications
- Product type: precision die-cast structural component
- Connector / hardware family: SFP
- Process: precision die casting with secondary machining or finishing as required by drawing
- Application focus: connector housing, cage, shell, heatsink carrier, or industrial structural part
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
SFP+Structural Part 8 Specifications
Product typeprecision die-cast structural component
Connector / hardware familySFP
Processprecision die casting with secondary machining or finishing as required by drawing
Application focusconnector housing, cage, shell, heatsink carrier, or industrial structural part
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm alloy, dimensional tolerance, tooling status, surface finish, machining operations, inspection criteria, and drawing revision
Typical Applications
SFP+ transceiver module structural housings for 10G networking
Colocation and cloud data center optical interconnect modules
Telecom access network SFP+ ONU and OLT transceiver components
Industrial switch SFP+ modules for harsh environment deployment
High-performance computing cluster 10G SFP+ interconnect modules
Frequently Asked Questions
What quality certifications does CZT hold for this die-cast component?
CZT's manufacturing facility operates under ISO 9001 quality management certification. Additional certifications including IATF 16949 for automotive-grade production and UL recognition for applicable components are available. Full quality documentation packages are provided for OEM qualification programs.
How does CZT handle engineering changes to existing SFP+ structural part tooling?
Engineering change requests are processed through a formal ECR/ECN workflow. CZT evaluates tooling modification feasibility, provides cost and lead time impact assessment, and manages first article re-qualification before production release of modified components.
What is the expected tooling life for this precision die-cast component?
Die tooling for zinc alloy components typically achieves 500,000 to 1,000,000 shots under normal production conditions with scheduled maintenance. Aluminum alloy tooling life is generally 100,000 to 300,000 shots. CZT monitors tool wear and proactively schedules refurbishment to maintain dimensional compliance.
SFP+Structural Part 8 Details
CategoryIndustrial
SubcategoryPrecision Die Casting
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
