Industrial / Precision Die Casting
SFP Structural Part 8
Die-cast SFP structural part designed to house and protect transceiver components while maintaining precise alignment with host board cage assemblies. The precision casting process provides excellent dimensional repeatability and mechanical durability. Applicable in high-density networking line cards, wireless backhaul equipment, and industrial communication modules.
Key Features
- Die-cast housing provides precise component alignment within SFP transceiver assembly
- Integrated retention features secure optical and electrical subcomponents reliably
- High-pressure die casting delivers consistent wall thickness and structural integrity
- Compatible with standard SFP cage and bail latch mechanisms
- Optimized geometry minimizes insertion force while maintaining secure module retention
Key Specifications
- Product type: precision die-cast structural component
- Connector / hardware family: SFP
- Process: precision die casting with secondary machining or finishing as required by drawing
- Application focus: connector housing, cage, shell, heatsink carrier, or industrial structural part
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
SFP Structural Part 8 Specifications
Product typeprecision die-cast structural component
Connector / hardware familySFP
Processprecision die casting with secondary machining or finishing as required by drawing
Application focusconnector housing, cage, shell, heatsink carrier, or industrial structural part
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm alloy, dimensional tolerance, tooling status, surface finish, machining operations, inspection criteria, and drawing revision
Typical Applications
SFP transceiver optical subassembly enclosure and protection
High-density line card SFP module mechanical housing
Industrial automation SFP interface structural component
Wireless base station optical transceiver module assembly
Metro Ethernet SFP transceiver protective housing
Frequently Asked Questions
How does SFP Structural Part 8 protect internal transceiver components?
The die-cast housing provides a rigid enclosure that shields optical and electrical subcomponents from mechanical shock, vibration, and handling stress. The precise internal geometry maintains component alignment to prevent signal degradation caused by physical displacement during operation or field replacement.
Is this part compatible with both single-mode and multimode SFP transceivers?
The structural part is designed to the standard SFP MSA mechanical footprint, making it compatible with both single-mode and multimode transceiver variants. Optical aperture dimensions and internal clearances accommodate standard LC and other common connector interfaces.
What are the typical production lead times and minimum order quantities?
Standard lead times for die-cast structural parts range from 4 to 8 weeks depending on order volume and surface finish requirements. Contact CZT sales for MOQ details and tooling amortization options for high-volume procurement programs.
SFP Structural Part 8 Details
CategoryIndustrial
SubcategoryPrecision Die Casting
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
