Industrial / Precision Die Casting
SFP+Structural Part 9
Precision die-cast structural part for SFP+ transceiver modules, providing the mechanical backbone required for proper module alignment, latching, and thermal contact with host cage assemblies. Its accurate casting geometry supports high-volume manufacturing with minimal post-processing. Used in data center networking, wireless backhaul equipment, and carrier-grade optical systems.
Key Features
- Precision die-cast aluminum alloy construction for SFP+ transceiver modules
- Tight dimensional tolerances ensure proper PCB alignment and mating
- Integrated EMI shielding cage structure for high-frequency signal integrity
- Surface finish optimized for corrosion resistance in industrial environments
- Designed to meet SFP+ MSA mechanical specification requirements
Key Specifications
- Product type: precision die-cast structural component
- Connector / hardware family: SFP
- Process: precision die casting with secondary machining or finishing as required by drawing
- Application focus: connector housing, cage, shell, heatsink carrier, or industrial structural part
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
SFP+Structural Part 9 Specifications
Product typeprecision die-cast structural component
Connector / hardware familySFP
Processprecision die casting with secondary machining or finishing as required by drawing
Application focusconnector housing, cage, shell, heatsink carrier, or industrial structural part
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm alloy, dimensional tolerance, tooling status, surface finish, machining operations, inspection criteria, and drawing revision
Typical Applications
SFP+ optical transceiver module housing assemblies
10G Ethernet switch and router line cards
Industrial fiber optic communication equipment
Data center active optical cable terminations
Telecom base station optical interface modules
Frequently Asked Questions
What die casting alloy is used for this SFP+ structural part?
The part is manufactured using precision zinc or aluminum die casting alloys selected for dimensional stability and EMI shielding performance. Specific alloy grades are available upon request and can be confirmed against your design requirements before production.
Does this structural part comply with SFP+ MSA mechanical specifications?
Yes, the component is designed and manufactured to conform to the SFP+ Multi-Source Agreement (MSA) mechanical envelope. Dimensional inspection reports and first-article inspection documentation can be provided to verify compliance with your qualification process.
What surface treatment is applied to the die-cast structural part?
Standard surface treatments include nickel plating or chromate conversion coating to enhance corrosion resistance and maintain consistent contact with the host cage. Custom surface finishes are available depending on environmental and EMI requirements.
SFP+Structural Part 9 Details
CategoryIndustrial
SubcategoryPrecision Die Casting
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
