SFP Structural Part 9
Precision die-cast structural component for SFP transceiver modules, engineered to withstand mechanical stress from repeated plug-and-pull operations while preserving interface geometry. Consistent casting quality ensures compatibility with standard SFP cage specifications. Commonly found in carrier-grade networking hardware, surveillance systems, and industrial Ethernet infrastructure.
Key Features
- Engineered to withstand high-cycle mechanical stress from repeated plug-and-pull operations
- Precision die-cast construction maintains alignment under thermal expansion conditions
- Robust latch interface geometry resists deformation over extended service life
- Alloy selection optimized for balance of strength, weight, and machinability
- Dimensional repeatability supports automated transceiver assembly processes
Key Specifications
- Product type: precision die-cast structural component
- Connector / hardware family: SFP
- Process: precision die casting with secondary machining or finishing as required by drawing
- Application focus: connector housing, cage, shell, heatsink carrier, or industrial structural part
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
SFP Structural Part 9 Specifications
Product typeprecision die-cast structural component
Connector / hardware familySFP
Processprecision die casting with secondary machining or finishing as required by drawing
Application focusconnector housing, cage, shell, heatsink carrier, or industrial structural part
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm alloy, dimensional tolerance, tooling status, surface finish, machining operations, inspection criteria, and drawing revision
Typical Applications
High-cycle SFP hot-swap applications in network equipment
Field-replaceable transceiver modules in harsh industrial environments
Data center infrastructure requiring frequent transceiver maintenance
Telecom central office SFP module structural component
Test and measurement equipment SFP interface assemblies
Frequently Asked Questions
How many mating cycles is SFP Structural Part 9 rated for?
The part is engineered to support the SFP MSA standard minimum of 200 mating cycles, with design margins that typically exceed this in practice. For applications requiring higher cycle ratings, CZT can evaluate material and surface treatment options to extend service life.
How does the die-cast structure perform under thermal cycling conditions?
The alloy and geometry are selected to minimize differential thermal expansion relative to PCB and cage materials. This maintains dimensional alignment across the operating temperature range, preventing misalignment-induced optical coupling loss or electrical contact degradation during thermal cycling.
Can CZT provide custom modifications to the standard structural geometry?
Yes, CZT offers custom tooling and geometry modifications to accommodate non-standard transceiver designs, unique retention mechanisms, or application-specific clearance requirements. Engineering samples and DFM review are available prior to production tooling commitment.
SFP Structural Part 9 Details
CategoryIndustrial
SubcategoryPrecision Die Casting
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
