SRQ-YZ-15
The SRQ-YZ-15 heat sink offers a practical passive cooling solution for mid-range power dissipation requirements in industrial applications. Its extruded aluminum profile can be cut to custom lengths, providing flexibility during system integration. Commonly deployed in variable frequency drives, charging equipment, and power conditioning units.
Key Features
- Mid-range power dissipation capacity suited for 10–50W thermal loads
- Straight-fin extrusion profile optimized for vertical natural convection mounting
- Uniform base thickness ensures even heat spreading across component footprint
- Anodized black finish enhances radiative thermal emission performance
- Standard bolt-pattern compatibility with TO-3P and similar power packages
Key Specifications
- Product type: heat sink / thermal management component
- Application focus: optical transceiver, networking, power electronics, or industrial electronics thermal management
- Material: aluminum alloy reference; confirm final alloy, temper, and finish during RFQ
- Process note: confirm extrusion, die casting, CNC machining, skiving, bonding, or surface finishing from the customer drawing
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
SRQ-YZ-15 Specifications
Product typeheat sink / thermal management component
Application focusoptical transceiver, networking, power electronics, or industrial electronics thermal management
Materialaluminum alloy reference; confirm final alloy, temper, and finish during RFQ
Process noteconfirm extrusion, die casting, CNC machining, skiving, bonding, or surface finishing from the customer drawing
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm dimensions, fin geometry, thermal interface, mounting method, surface finish, packaging, and drawing revision
Typical Applications
Passive cooling of mid-power IGBT modules in drives
Heat management for linear voltage regulators in industrial PSUs
Thermal dissipation for rectifier bridges in battery chargers
Cooling power transistors in industrial welding equipment
Heat sinking for thyristors in soft-starter control boards
Frequently Asked Questions
What power dissipation range is the SRQ-YZ-15 designed for?
The SRQ-YZ-15 targets mid-range dissipation applications, typically 10–50W depending on ambient temperature and airflow. For accurate sizing, calculate required thermal resistance using Rth = (Tj_max - Ta) / P and compare against the product's rated specification.
Does fin orientation affect the SRQ-YZ-15's thermal performance?
Yes, significantly. For natural convection, fins should be oriented vertically to allow chimney-effect airflow. Horizontal fin orientation can reduce convective efficiency by up to 30%. Always mount the SRQ-YZ-15 with fins vertical unless forced airflow is present.
Is the SRQ-YZ-15 compatible with thermal interface pads?
Yes. The flat machined base is compatible with thermal interface pads, phase-change materials, and thermal grease. For production environments, pre-cut thermal pads offer consistent, repeatable contact resistance and simplify assembly compared to manually applied paste.
SRQ-YZ-15 Details
CategoryIndustrial
SubcategoryHeat Sinks
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
