592*4小插芯扁针 Flat Pin Series
Model:592*4小插芯扁针
The 592×4 Small Insert Flat Pin is a compact-format gold-plated contact designed for insertion into small-core connector housings, offering a reliable electrical interface in a reduced footprint. Its flat-pin geometry facilitates straightforward assembly and consistent contact force during mating. Typical applications include miniature lighting connectors, compact consumer electronics, and space-sensitive PCB edge interfaces.
Key Features
- Compact-format gold-plated contact designed for small-core connector housings
- Optimized insertion geometry for reliable engagement in miniature connector bodies
- Gold plating ensures low contact resistance in space-constrained applications
- Suitable for high-density connector assemblies requiring small insert contacts
- Consistent dimensional tolerances support repeatable automated insertion
Key Specifications
- Service type: connector terminal electroplating / selective plating
- Connector family: Custom connector or industrial hardware
- Plating focus: gold, nickel, tin, or selective plating stack per customer drawing and RFQ requirements
- Quality focus: appearance, adhesion, bending performance, contact zone consistency, and batch color control where applicable
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
Flat Pin Series Specifications
Service typeconnector terminal electroplating / selective plating
Connector familyCustom connector or industrial hardware
Plating focusgold, nickel, tin, or selective plating stack per customer drawing and RFQ requirements
Quality focusappearance, adhesion, bending performance, contact zone consistency, and batch color control where applicable
Drawing statusRequest Drawing or plating specification during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm substrate material, plating stack, thickness, contact area, reel / barrel / rack process, masking requirements, test method, and inspection criteria
Typical Applications
Small-core miniature connector housings in portable electronics
Compact signal interface connectors in wearable devices
High-density PCB connector assemblies with small insert contacts
Miniaturized industrial sensor connector contacts
Fine-pitch connector contacts in medical diagnostic equipment
Frequently Asked Questions
What does 'small insert' mean in the context of the 592×4 Small Insert Flat Pin?
Small insert refers to the contact's core dimensions being sized for smaller connector housing cavities within the 592×4 series. This allows designers to use the same housing family while selecting contact size based on current rating and space constraints, providing flexibility in connector system design.
How does the 592×4 Small Insert compare to the Large Insert variant?
The Small Insert has a reduced contact surface area suited for lower current or signal-only circuits, while the Large Insert provides greater contact area for higher current applications. Both share the same 592×4 housing compatibility, allowing mixed contact sizes within a single connector assembly.
Is the 592×4 Small Insert Flat Pin suitable for automated assembly?
Yes. The consistent dimensional tolerances and defined insertion geometry of the 592×4 Small Insert support automated contact insertion into connector housings. Contact CZT for tape-and-reel or strip packaging options that are compatible with your automated assembly equipment.
Flat Pin Series Details
CategoryIndustrial
SubcategoryElectroplating
Model Number592*4小插芯扁针
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
