SRQ-HJ-04
The SRQ-HJ-04 is a precision heat sink designed for thermal management of optical transceiver modules and power electronics in high-speed networking and industrial applications. Featuring an advanced fin construction for maximum surface area and thermal performance, this heat sink is optimized for active cooling environments where high-power optical modules or switch ASICs require aggressive heat dissipation to maintain reliable operation. Its aluminum alloy construction and precision-machined mounting surface ensure optimal thermal contact and long-term performance stability in 24/7 data center and carrier network equipment.
Key Features
- Precision-machined contact surface ensures minimal thermal interface resistance
- Dual-purpose design supports both optical transceivers and power electronics cooling
- Mounting hole pattern compatible with standard PCB and cage assembly layouts
- Extruded aluminum profile with optimized fin pitch for balanced airflow impedance
- RoHS-compliant materials suitable for industrial and telecom-grade applications
Key Specifications
- Product type: heat sink / thermal management component
- Application focus: optical transceiver, networking, power electronics, or industrial electronics thermal management
- Material: aluminum alloy reference; confirm final alloy, temper, and finish during RFQ
- Process note: confirm extrusion, die casting, CNC machining, skiving, bonding, or surface finishing from the customer drawing
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
SRQ-HJ-04 Specifications
Product typeheat sink / thermal management component
Application focusoptical transceiver, networking, power electronics, or industrial electronics thermal management
Materialaluminum alloy reference; confirm final alloy, temper, and finish during RFQ
Process noteconfirm extrusion, die casting, CNC machining, skiving, bonding, or surface finishing from the customer drawing
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm dimensions, fin geometry, thermal interface, mounting method, surface finish, packaging, and drawing revision
Typical Applications
Optical transceiver module thermal management in switching platforms
Power electronics heat dissipation on high-density PCB assemblies
FPGA and network processor thermal regulation in line cards
Industrial control board component cooling in enclosed cabinets
Telecom equipment power amplifier thermal management
Frequently Asked Questions
What makes the SRQ-HJ-04 suitable for both optical and power electronics applications?
The SRQ-HJ-04 features a flat, precision-machined base that provides reliable thermal contact across different component footprints. Its mounting pattern and fin geometry are designed to accommodate the thermal profiles of both optical transceiver modules and surface-mount power components on standard PCB layouts.
Is the SRQ-HJ-04 RoHS compliant?
Yes. The SRQ-HJ-04 is manufactured using RoHS-compliant aluminum alloy and surface treatment processes, making it suitable for use in telecom, industrial, and enterprise networking equipment that must meet EU RoHS and similar environmental compliance requirements.
What fin pitch does the SRQ-HJ-04 use, and how does it affect airflow?
The SRQ-HJ-04 uses an optimized fin pitch that balances surface area and airflow impedance. A tighter pitch increases heat transfer area but raises pressure drop; the SRQ-HJ-04's geometry is tuned for typical chassis fan speeds, ensuring effective cooling without excessive flow restriction.
SRQ-HJ-04 Details
CategoryIndustrial
SubcategoryHeat Sinks
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
