SRQ-HJ-15
The SRQ-HJ-15 (SRQ-HJ-15) is an industrial heat sink engineered for high-efficiency thermal dissipation in space-constrained electronic enclosures. Its extruded aluminum fin profile offers an excellent strength-to-weight ratio while maintaining low thermal resistance, making it a preferred choice for DIN-rail mounted controllers, frequency converters, and compact power supplies. The SRQ-HJ-15 supports both passive and low-velocity forced-air cooling configurations.
Key Features
- High-efficiency thermal dissipation optimized for space-constrained installations
- Slim profile enables deployment in 1U rack and compact enclosure formats
- Extruded fin structure maximizes surface-to-volume ratio within tight footprints
- Compatible with both natural convection and low-velocity forced-air cooling
- Precision base flatness reduces thermal interface resistance at device contact
Key Specifications
- Product type: heat sink / thermal management component
- Application focus: optical transceiver, networking, power electronics, or industrial electronics thermal management
- Material: aluminum alloy reference; confirm final alloy, temper, and finish during RFQ
- Process note: confirm extrusion, die casting, CNC machining, skiving, bonding, or surface finishing from the customer drawing
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
SRQ-HJ-15 Specifications
Product typeheat sink / thermal management component
Application focusoptical transceiver, networking, power electronics, or industrial electronics thermal management
Materialaluminum alloy reference; confirm final alloy, temper, and finish during RFQ
Process noteconfirm extrusion, die casting, CNC machining, skiving, bonding, or surface finishing from the customer drawing
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm dimensions, fin geometry, thermal interface, mounting method, surface finish, packaging, and drawing revision
Typical Applications
Cooling power semiconductors in 1U rack-mount power supplies
Thermal management in compact industrial automation controllers
Heat dissipation for telecom rectifier modules in tight chassis
Passive cooling of DC-DC converters in embedded systems
Thermal control in space-constrained medical power equipment
Frequently Asked Questions
How does the SRQ-HJ-15 perform in low-airflow environments?
The SRQ-HJ-15 is engineered to deliver effective passive cooling even in low-airflow conditions by maximizing fin surface area within its compact envelope. For applications with near-zero airflow, thermal derating should be applied per the datasheet curves to ensure junction temperatures remain within safe limits.
Is the SRQ-HJ-15 compatible with 1U server or rack enclosures?
Yes. The slim profile of the SRQ-HJ-15 is specifically suited for 1U and 2U rack-mount enclosures where vertical clearance is limited. Verify fin height against available chassis clearance before installation to ensure unobstructed airflow through the fin channels.
Can the SRQ-HJ-15 be cut or machined to custom lengths?
Extruded aluminum heat sinks like the SRQ-HJ-15 can generally be cut to custom lengths using standard metalworking tools. Deburring cut edges is essential to prevent fin damage and maintain airflow efficiency. Contact CZT for pre-cut custom length options if volume requirements justify it.
SRQ-HJ-15 Details
CategoryIndustrial
SubcategoryHeat Sinks
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
