SRQ-HJ-12
The SRQ-HJ-12 (SRQ-HJ-12) is an industrial-grade heat sink engineered to manage thermal loads in demanding electronic assemblies. Its optimized fin geometry maximizes surface area for convective heat transfer, making it an ideal solution for power modules, IGBT drivers, and industrial control boards. Built to RoHS standards, the SRQ-HJ-12 delivers consistent thermal performance across a wide operating temperature range, supporting long-term reliability in factory automation and energy conversion applications.
Key Features
- Industrial-grade aluminum alloy construction withstands harsh operating environments
- High fin density increases convective surface area for elevated thermal loads
- Flat lapped base surface minimizes contact resistance with power device packages
- Compatible with clip, screw, and adhesive mounting methods
- Suitable for continuous operation across wide ambient temperature ranges
Key Specifications
- Product type: heat sink / thermal management component
- Application focus: optical transceiver, networking, power electronics, or industrial electronics thermal management
- Material: aluminum alloy reference; confirm final alloy, temper, and finish during RFQ
- Process note: confirm extrusion, die casting, CNC machining, skiving, bonding, or surface finishing from the customer drawing
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
SRQ-HJ-12 Specifications
Product typeheat sink / thermal management component
Application focusoptical transceiver, networking, power electronics, or industrial electronics thermal management
Materialaluminum alloy reference; confirm final alloy, temper, and finish during RFQ
Process noteconfirm extrusion, die casting, CNC machining, skiving, bonding, or surface finishing from the customer drawing
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm dimensions, fin geometry, thermal interface, mounting method, surface finish, packaging, and drawing revision
Typical Applications
Thermal control of IGBT modules in inverter systems
Heat dissipation for industrial switching power supplies
Cooling rectifier bridges in three-phase power conversion
Temperature management of PLCs and industrial controllers
Passive cooling for ruggedized embedded computing boards
Frequently Asked Questions
What is the typical thermal resistance of the SRQ-HJ-12?
Exact thermal resistance values depend on airflow conditions and mounting configuration. For precise figures, refer to the product datasheet or contact CZT engineering support. Generally, industrial-grade heat sinks in this series are rated for natural convection dissipation in the range of several watts per degree Celsius.
Can the SRQ-HJ-12 be used in vertically mounted orientations?
Yes. The fin orientation on the SRQ-HJ-12 is designed to support vertical mounting, which promotes natural convective airflow along the fin channels. Horizontal mounting is also possible but may slightly reduce passive cooling efficiency due to reduced chimney effect.
What surface treatment does the SRQ-HJ-12 have?
The SRQ-HJ-12 features an anodized surface treatment that improves thermal emissivity for better radiative heat transfer, while also providing corrosion protection suitable for industrial environments with humidity, dust, or mild chemical exposure.
SRQ-HJ-12 Details
CategoryIndustrial
SubcategoryHeat Sinks
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
