SRQ-XJ-20
The SRQ-XJ-20 is a passive heat sink built for consistent thermal performance across a wide range of industrial applications. CZT's aluminum alloy construction ensures low thermal resistance and long service life. Typical installations include LED drivers, switching regulators, and automation control panels.
Key Features
- Passive cooling design eliminates fan dependency for maintenance-free operation
- Wide operating temperature range suits diverse industrial application environments
- Consistent thermal performance across varying load cycles and ambient conditions
- Aluminum extrusion profile supports flexible mounting and integration options
- Suitable for both PCB-mount and chassis-mount power component configurations
Key Specifications
- Product type: heat sink / thermal management component
- Application focus: optical transceiver, networking, power electronics, or industrial electronics thermal management
- Material: aluminum alloy reference; confirm final alloy, temper, and finish during RFQ
- Process note: confirm extrusion, die casting, CNC machining, skiving, bonding, or surface finishing from the customer drawing
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
SRQ-XJ-20 Specifications
Product typeheat sink / thermal management component
Application focusoptical transceiver, networking, power electronics, or industrial electronics thermal management
Materialaluminum alloy reference; confirm final alloy, temper, and finish during RFQ
Process noteconfirm extrusion, die casting, CNC machining, skiving, bonding, or surface finishing from the customer drawing
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm dimensions, fin geometry, thermal interface, mounting method, surface finish, packaging, and drawing revision
Typical Applications
Passive cooling in sealed industrial control enclosures
Power transistor heat dissipation in field-deployed equipment
Thermal management in railway and transportation electronics
Heat sinking for power regulators in building automation systems
Cooling for rectifier assemblies in off-grid power systems
Frequently Asked Questions
What are the advantages of passive cooling for industrial applications?
Passive heat sinks eliminate moving parts, removing the primary failure mode in active cooling systems. This is critical in sealed enclosures, remote installations, or environments where fan maintenance is impractical. The SRQ-XJ-20 delivers reliable, silent thermal management with zero ongoing maintenance requirements.
How does the SRQ-XJ-20 perform across wide ambient temperature swings?
The SRQ-XJ-20 is designed for consistent thermal performance across a broad ambient temperature range typical of industrial deployments. Aluminum's stable thermal conductivity across temperature ensures predictable junction temperatures. Verify derating curves against your worst-case ambient when sizing for your application.
Can the SRQ-XJ-20 be used in both horizontal and vertical mounting positions?
Yes, though vertical fin orientation is recommended for passive installations to maximize natural convection efficiency. Horizontal mounting is acceptable in forced-air or conduction-cooled enclosures. CZT can provide orientation-specific thermal resistance data to support your system thermal design.
SRQ-XJ-20 Details
CategoryIndustrial
SubcategoryHeat Sinks
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
