SRQ-XJ-22
The SRQ-XJ-22 heat sink is engineered to handle heat dissipation requirements of medium to high-power electronic assemblies. Its extruded profile supports direct mounting of TO-package and surface-mount power devices. Well suited for use in frequency converters, welding equipment, and industrial power conditioning units.
Key Features
- Engineered for medium to high-power electronic assembly heat dissipation requirements
- Optimized fin density balances thermal resistance and airflow pressure drop
- Robust aluminum construction handles cyclic thermal loading without deformation
- Multiple mounting hole configurations support diverse power device footprints
- Compatible with thermal interface pads and grease for flexible assembly processes
Key Specifications
- Product type: heat sink / thermal management component
- Application focus: optical transceiver, networking, power electronics, or industrial electronics thermal management
- Material: aluminum alloy reference; confirm final alloy, temper, and finish during RFQ
- Process note: confirm extrusion, die casting, CNC machining, skiving, bonding, or surface finishing from the customer drawing
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
SRQ-XJ-22 Specifications
Product typeheat sink / thermal management component
Application focusoptical transceiver, networking, power electronics, or industrial electronics thermal management
Materialaluminum alloy reference; confirm final alloy, temper, and finish during RFQ
Process noteconfirm extrusion, die casting, CNC machining, skiving, bonding, or surface finishing from the customer drawing
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm dimensions, fin geometry, thermal interface, mounting method, surface finish, packaging, and drawing revision
Typical Applications
Medium to high-power inverter and converter thermal management
Industrial power supply heat dissipation in control cabinets
Cooling for multi-device power assemblies on shared heat sinks
Heat dissipation in EV charging station power electronics
Thermal management for industrial welding inverter stages
Frequently Asked Questions
Can multiple power devices be mounted on a single SRQ-XJ-22?
Yes. The SRQ-XJ-22 mounting surface is sized to accommodate multiple discrete devices or a combination of devices and modules. When mounting multiple components, ensure thermal interface material is applied uniformly and account for the cumulative power dissipation in your thermal resistance calculations.
What fin density does the SRQ-XJ-22 use, and how does it affect airflow?
The SRQ-XJ-22 uses an optimized fin pitch that balances surface area for heat transfer against airflow impedance. Tighter fin spacing increases surface area but raises pressure drop, which can reduce airflow in fan-cooled systems. The selected geometry suits both natural convection and moderate forced-air applications.
Is the SRQ-XJ-22 suitable for EV charging infrastructure applications?
Yes. EV charging stations require reliable thermal management for high-power switching devices operating in variable ambient conditions. The SRQ-XJ-22's robust construction and thermal performance make it well-suited for this application. Confirm your power dissipation and ambient temperature requirements with CZT for proper sizing.
SRQ-XJ-22 Details
CategoryIndustrial
SubcategoryHeat Sinks
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
