SRQ-SLB-11-2
The SRQ-SLB-11-2 is an alternate-configuration variant of the SRQ-SLB-11 series heat sink, adapted for devices with different lead or tab orientations. It shares the same aluminum alloy base material and fin geometry as the SRQ-SLB-11-1 for consistent thermal performance. Applicable in power electronics assemblies, industrial control modules, and custom OEM designs.
Key Features
- Alternate mounting configuration accommodates non-standard or offset device tab geometries
- Shares SRQ-SLB-11 series fin array for equivalent thermal dissipation performance
- Designed for drop-in replacement in layouts where standard hole patterns are unsuitable
- Extruded 6063 aluminum construction with consistent fin pitch across the array
- Anodized finish provides corrosion resistance in humid industrial environments
Key Specifications
- Product type: heat sink / thermal management component
- Application focus: optical transceiver, networking, power electronics, or industrial electronics thermal management
- Material: aluminum alloy reference; confirm final alloy, temper, and finish during RFQ
- Process note: confirm extrusion, die casting, CNC machining, skiving, bonding, or surface finishing from the customer drawing
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
SRQ-SLB-11-2 Specifications
Product typeheat sink / thermal management component
Application focusoptical transceiver, networking, power electronics, or industrial electronics thermal management
Materialaluminum alloy reference; confirm final alloy, temper, and finish during RFQ
Process noteconfirm extrusion, die casting, CNC machining, skiving, bonding, or surface finishing from the customer drawing
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm dimensions, fin geometry, thermal interface, mounting method, surface finish, packaging, and drawing revision
Typical Applications
Power modules with non-standard tab hole spacing requiring custom heatsink fit
Retrofit thermal upgrades on legacy industrial control boards
Multi-device assemblies with mixed package mounting orientations
Industrial inverter designs with constrained PCB real estate
Custom OEM power electronics requiring flexible heatsink mounting options
Frequently Asked Questions
Can the SRQ-SLB-11-2 be used interchangeably with the SRQ-SLB-11-1?
Not directly — the two variants differ in mounting hole position or pattern to suit different device tab geometries. Thermal performance is equivalent, but mechanical fit depends on your specific semiconductor package. Always verify hole spacing and base dimensions against your device datasheet before substituting one variant for the other.
Does the alternate configuration affect the thermal resistance of the SRQ-SLB-11-2?
No. The fin array geometry and base thickness are identical across the SRQ-SLB-11 series. Thermal resistance values are the same between the -11-1 and -11-2 variants. Any difference in effective Rth(j-a) comes from the mounting interface quality and TIM selection, not the heatsink itself.
What industries typically use the SRQ-SLB-11-2?
The SRQ-SLB-11-2 is commonly used in industrial automation, power conversion, and OEM equipment manufacturing where non-standard device footprints are encountered. It is also popular in retrofit and repair applications where the original heatsink is discontinued and a compatible alternate-pattern replacement is needed.
SRQ-SLB-11-2 Details
CategoryIndustrial
SubcategoryHeat Sinks
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
