SRQ-XJ-01
The SRQ-XJ-01 is an industrial heat sink from CZT's XJ series, featuring a clip-mount or screw-mount compatible base for quick component installation. Its aluminum fin structure supports passive cooling in moderate thermal load scenarios. Commonly specified for TO-220 and similar package semiconductors in power regulation and signal conditioning circuits.
Key Features
- Clip-mount and screw-mount compatible base supports flexible assembly methods
- XJ series design optimized for efficient heat spreading from TO-package devices
- Compact profile suitable for moderate-density PCB and panel-mount installations
- Extruded aluminum construction with uniform fin spacing for predictable airflow
- Versatile mounting options reduce assembly time in high-volume production lines
Key Specifications
- Product type: heat sink / thermal management component
- Application focus: optical transceiver, networking, power electronics, or industrial electronics thermal management
- Material: aluminum alloy reference; confirm final alloy, temper, and finish during RFQ
- Process note: confirm extrusion, die casting, CNC machining, skiving, bonding, or surface finishing from the customer drawing
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
SRQ-XJ-01 Specifications
Product typeheat sink / thermal management component
Application focusoptical transceiver, networking, power electronics, or industrial electronics thermal management
Materialaluminum alloy reference; confirm final alloy, temper, and finish during RFQ
Process noteconfirm extrusion, die casting, CNC machining, skiving, bonding, or surface finishing from the customer drawing
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm dimensions, fin geometry, thermal interface, mounting method, surface finish, packaging, and drawing revision
Typical Applications
TO-220 linear regulator cooling on industrial control boards
Power MOSFET thermal management in switching power supplies
Clip-mounted heatsinking for rapid prototyping and field repair
Low-to-mid power rectifier diode cooling in AC-DC converters
Consumer and industrial electronics requiring flexible heatsink attachment
Frequently Asked Questions
What clip types are compatible with the SRQ-XJ-01 clip-mount base?
The SRQ-XJ-01 base is designed to accept standard push-on spring clips sized for TO-220 and similar packages. Clip compatibility depends on the specific clip manufacturer's tab width and spring force rating. CZT can advise on recommended clip part numbers for production assembly applications.
Is the SRQ-XJ-01 suitable for use inside sealed enclosures?
Yes, the SRQ-XJ-01 can be used in sealed enclosures relying on natural convection and conduction. However, thermal resistance will be higher than in open-air installations. For sealed enclosures, calculate worst-case ambient temperature rise and verify that junction temperatures remain within device ratings under maximum load.
Can the SRQ-XJ-01 be used without thermal interface material when clip-mounted?
It is not recommended. Even with clip mounting, surface irregularities between the device tab and heatsink base create air gaps that significantly increase contact resistance. A thin layer of thermal grease or a pre-applied phase-change pad ensures consistent, low-resistance thermal contact across the interface.
SRQ-XJ-01 Details
CategoryIndustrial
SubcategoryHeat Sinks
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
