SRQ-XJ-09
The SRQ-XJ-09 is a robust heat sink designed to handle the thermal demands of high-current industrial components in demanding duty-cycle applications. Constructed from aluminum alloy with a black anodized finish, it improves radiative heat dissipation in low-airflow installations. Used in welding equipment, industrial UPS systems, and heavy-duty power modules.
Key Features
- Heavy-duty construction rated for high-current industrial power component cooling
- Thick aluminum base minimizes thermal spreading resistance under large device footprints
- Robust fin array engineered for sustained high-power dissipation in demanding environments
- Corrosion-resistant anodized finish suitable for harsh industrial operating conditions
- Multiple mounting hole configurations support diverse chassis and PCB integration
Key Specifications
- Product type: heat sink / thermal management component
- Application focus: optical transceiver, networking, power electronics, or industrial electronics thermal management
- Material: aluminum alloy reference; confirm final alloy, temper, and finish during RFQ
- Process note: confirm extrusion, die casting, CNC machining, skiving, bonding, or surface finishing from the customer drawing
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
SRQ-XJ-09 Specifications
Product typeheat sink / thermal management component
Application focusoptical transceiver, networking, power electronics, or industrial electronics thermal management
Materialaluminum alloy reference; confirm final alloy, temper, and finish during RFQ
Process noteconfirm extrusion, die casting, CNC machining, skiving, bonding, or surface finishing from the customer drawing
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm dimensions, fin geometry, thermal interface, mounting method, surface finish, packaging, and drawing revision
